Arburg 320 M 500-210 I Injection Moulding I 1997
Specifications
| Manufacturer | Arburg |
| Model | 320 M 500-210 |
| Year | 1997 |
| Condition | Used |
| Stock Number | 600876408 |
| Pump operating | 19,038 H |
| Clamping force | 50 T |
| Screw diameter | 30 mm |
| Distance between tie bars | 320 x 320 mm |
| Shot volume | 144 cm³ |
| Shot weight | 120 g |
| Pressure on material | 1500 bar |
| Platen length | 490 mm |
| Platen width | 490 mm |
| Opening of the press | 375 mm |
| Mould size | 250 mm |
| Made in | Germany |
| Dimensions | L 4300 x W 1850 x H 1700 mm |
| Weight | 3060 kg |
| Availability | Immediately |
Description
Explore offering this pre-owned Arburg 320 M 500-210 Injection Moulding, manufactured in 1997 and currently located in Netherlands. This reliable plasticworking machine features a working area of 490 × 490 mm, a clamping force of 50 tons, and a press opening of 375 mm, making it well suited for precise and efficient production of small to medium-sized plastic components.
Advantages:
- Compact working area.
- Stable and consistent production performance.
- Proven Arburg reliability.
