SCM Startech CN Plus I CNC Drilling Center I 2020
Specifications
| Manufacturer | SCM |
| Model | Startech CN Plus |
| Year | 2020 |
| Condition | Used |
| Stock Number | 600875501 |
| Max panel dimensions in X-Y-Z | 3050 x 900 x 60 mm |
| Min panel dimensions in X-Y-Z | 200 x 80 x 10 mm |
| Drilling working area | 40/40/10 m/min |
| Vertical spindles | 8 (5X - 3Y) |
| Horizontal spindles | 6 (2+2X - 2Y) |
| Blade diameter | 125 mm |
| Blade thickness | 6 mm |
| Spindle speed | 4200 rpm |
| Blade rotating speed | 5500 rpm |
| Installed motor power | 15.2 kVA |
| Dimensions | L 3459 x W 2159 x H 1500 mm |
| Availability | Immediately |
Description
We hereby offer this used SCM Startech CN Plus CNC drilling center from 2020, located in Slovenia. It is capable of handling panels with maximum dimensions of 3050 x 900 x 60 mm, making it suitable for a wide range of applications in furniture and cabinetry production. The machine features a robust spindle with a 4200 rpm rotation speed, ensuring smooth and accurate performance. Additionally, it is equipped with a 125 mm blade diameter, offering versatile cutting capabilities.
Features:
- Screen protector.
- Led interior lighting.
- Regularly serviced.
- Barcode scanner.
- Maestro and Lestrojbox.
SCM Machinery
SCM, an esteemed Italian brand founded in 1952 and headquartered in Rimini, is a leading manufacturer of woodworking and metalworking machinery. Known for its unwavering commitment to innovation and precision, SCM offers a comprehensive range of equipment that caters to a diverse array of industries. In woodworking, SCM's portfolio includes CNC machining centers, edgebanders, panel saws, sanding machines, and drilling machines, while its metalworking solutions encompass CNC machining centers, metal cutting and forming equipment, and rolling machines. Additionally, SCM provides machinery for working with plastic and composite materials. With a rich legacy spanning decades, SCM is a trusted global partner, delivering advanced technology and superior craftsmanship to elevate manufacturing processes across various sectors.
