MAG-CX3 500 I CNC Milling I 2023
Specifiche
| Produttore | MAG-CX3 |
| Modello | 500 |
| Anno | 2023 |
| Condizione | Usato |
| Numero di magazzino | 600876123 |
| Number of axes | 3+1 |
| X-Axis travel | 485 mm |
| Y-Axis travel | 325 mm |
| Z-Axis travel | 190 mm |
| Precision | ± 0.01 mm |
| Type of spindle | ATC |
| Spindle speed | 30000 rpm |
| Maximum interpolated speed | 10000 mm/min |
| Absorbed power | 3 kW |
| Pneumatic operating pressure | 6 - 8 bar |
| Tool magazine | 6 positions |
| Type of cones | ISO 20 - ER20 |
| Dimensions | L 1620 x W 1010 x H 2040 mm |
| Weight | 720 kg |
| Availability | Immediately |
Descrizione
We hereby offer this used MAG-CX3 500 CNC milling machine from 2023, located in Spain. It features a working area of 485 x 325 mm, ideal for small to medium-sized components, and is equipped with a high-speed spindle reaching up to 30,000 rpm, ensuring exceptional accuracy in fine milling operations. With an absorbed power of 3 kW, this machine combines energy efficiency with reliable cutting performance. Designed for modern production needs, the MAG-CX3 500 delivers stability, precision, and versatility across a range of machining applications.
Advantages:
- High-Speed Spindle.
- Compact Working Area.
- Energy-Efficient Performance.
- Modern Design.
- Precision and Stability.
